Ventis Pro Series Multi Gas Detector

Stop carrying multiple instruments to meet your gas detection needs. The Ventis™ Pro Series has you covered whether you need unique four-gas or expanded five-gas sensor options, all in the most configurable multi-gas monitors on the market.

  • LENS™ Wireless allows personal monitors to communicate with area monitors
  • See gas readings and alarms from connected peers in LENS Wireless groups
  • Flexible sensor configurations detect up to five gases
  • Custom start-up messages, alarm action messages, and acknowledgeable gas alerts
  • Man-down alarm and dedicated panic button
  • User and site tracking with iAssign™ Technology
  • Rugged IP68 water and dust rating and Guaranteed for Life™ warranty
  • Available with or without a pump
  • Dock overdue and maintenance reminders
  • iNet ® and DSX™ Docking Station ready
  • Compatible with Ventis MX4 accessories including Ventis Slide-on pump

Overview

In your line of work, a day on the job can turn from habit to hazard in a single moment. Be ready for gas hazards and more with the Ventis Pro Series.

Detect up to five gases: Rely on flexible sensor options to detect combustible and toxic gases in a broad range of settings, making the Ventis Pro Series ideal for both personal protection and confined space applications.

Simplify gas detection for your users: Create custom start-up messages to communicate safety information to your team, see gas readings and alarms from connected peers using LENS Wireless , acknowledge low gas levels, and receive written instructions when an instrument goes into alarm.

React in emergency situations: Know when a worker is in distress or has lost consciousness thanks to a dedicated panic button and man-down alarm. Panic and man-down alarms will be relayed to other Ventis Pros in your group using LENS Wireless .

Track instruments and alarms: Address recurring alarms and improve asset management by assigning users and sites to each gas monitor in real time using iAssign™ Technology .

Depend on a rugged design:  Keep your instruments in the field, not the shop, thanks to an IP68 rating for dust and water ingress and a rugged overmold that is Guaranteed for Life™ .

Upgrade with ease: Don’t buy all new accessories. Most of your Ventis™ MX4 accessories are compatible with the Ventis Pro Series.

Technologies

LENS Wireless  is the first gas detection solution that allows personal monitors and area monitors to share gas readings and alarms with one another. Now when a gas hazard, man-down, or panic situation causes an instrument to alarm, all peers in the connected group will instantly be notified of the hazard and the person in danger. When seconds matter, you can rely on help from workers nearby, rather a call center hundreds of miles away.

iAssign Technology uses Near Field Communication (NFC) and Bluetooth technology to assign workers and locations to Ventis™ Pro Series gas detectors. Access to user and site data allows you to locate problem areas across your facility, stay compliant with clear and accurate record keeping, and alert workers when they enter restricted areas. iAssign provides a more complete picture of what’s happening across a worksite, enabling safety managers to take action to prevent repeated hazards.

DualSense Technology uses redundant sensors to determine the concentration of the target gas in the atmosphere and reduce the risk of instrument failure. Two sensors of the same type in one gas detector help to give you the most accurate gas reading.

Common Configuration Ventis Pro 5

Part Number Description
VP5-KJ5Y2111ywz Ventis Pro5 with pump – LEL (Pent), CO/H2S, SO2, O2, Extended Li-ion, Desktop Charger, Safety Orange
VP5-KJ4Y1101ywz Ventis Pro5 – LEL (Pent), CO/H2S, NO2, O2, Li-ion, Desktop Charger, Safety Orange
VP5-KJ6Y2110ywz Ventis Pro5 with pump – LEL (Pent), CO/H2S, NH3, O2, Extended Li-ion, Desktop Charger, Black
VP5-U12Y2110ywz Ventis Pro5 with pump – CO2/LEL IR, CO, H2S, O2, Extended Li-ion, Desktop Charger, Black
VP5-U16Y2111ywz Ventis Pro5 with pump – CO2/LEL IR, CO, NH3, O2, Extended Li-ion, Desktop Charger, Safety Orange
y = Agency Certification: 1 = UL/CSA, 2 = ATEX/IECEx
w = Wireless: 0 = Non-wireless, 1 = Wireless
z = Language for included Reference Guide: 1 = EN, 2 = FR, 3 = ES, 4 = DE, 5 = IT, 6 = DU, 7 = PT, A = PL

Common Configuration Ventis Pro 4

Part Number Description
VP4-K12Y1101ywz Ventis Pro4 – LEL (Pent), CO, H2S, O2, Li-ion, Desktop Charger, Safety Orange
VP4-K12Y2110ywz Ventis Pro4 with pump – LEL (Pent), CO, H2S, O2, Extended Li-ion, Desktop Charger, Black
VP4-K52Y1101ywz Ventis Pro4 – LEL (Pent), SO2, H2S, O2, Li-ion, Desktop Charger, Safety Orange
VP4-K14Y1101ywz Ventis Pro4 – LEL (Pent), CO, NO2, O2, Li-ion, Desktop Charger, Safety Orange
VP4-K1BY1101ywz Ventis Pro4 – LEL (Pent), CO, HCN, O2, Li-ion, Desktop Charger, Safety Orange
VP4-K1BY2111ywz Ventis Pro4 with pump – LEL (Pent), CO, HCN, O2, Extended Li-ion, Desktop Charger, Safety Orange
y = Agency Certification: 1 = UL/CSA, 2 = ATEX/IECEx
w = Wireless: 0 = Non-wireless, 1 = Wireless
z = Language for included Reference Guide: 1 = EN, 2 = FR, 3 = ES, 4 = DE, 5 = IT, 6 = DU, 7 = PT, A = PL

Industry-Specific Configurations

INDUSTRY DESCRIPTION HAZARD
Oil & Gas Refining Standard 4-Gas + SO2 SO2 released when oil burns
Oil & Gas Exploration Standard 4-Gas + CO2 CO2 used in fracking
Fire Fighting Standard 4-Gas +HCN HCN release in burning plastics
Power Generation Standard 4-Gas +SO2 Burning coal or oil for fuel
Refrigeration NH3 or CO2 NH3 and CO2 are coolants
Gas Utility CH4, IR, CO, O2 High-range CH4 detection
Steel CO, H2S, SO2, NH3 Four toxics
Coal Mining CH4 IR (Dual Range) One instrument for personal protection and seal checking
Metal Mining Standard 4-Gas + HCN Cyanide used to separate gold from rock

Specification

INSTRUMENT WARRANTY

Guaranteed for Life. Warranted for as long as the instrument is supported by Industrial Scientific Corporation (excludes sensors, batteries, and filters). O2, LEL, CO, and H2S sensors warranted for three years. All other sensors warranted for two years. Pumps and batteries are warranted for two years.

KEYPAD

Two buttons for operation. Dedicated panic button.

DATA LOG

At least 3 months at 10-second intervals

EVENT LOGGING

60 alarm events

INGRESS PROTECTION

IP68 (submersion at 1.5 meters for 1 hour)

CASE MATERIAL

Polycarbonate with protective rubber overmold

DIMENSIONS

104 x 58 x 36 mm (4.1 x 2.3 x 1.4 in) without pump

172 x 67 x 65 mm (6.8 x 2.6 x 2.6 in) with pump

WEIGHT

200 g (7.05 oz), typical without pump

390 g (13.76 oz), typical with pump

TEMPERATURE RANGE

-40° C to 50 °C (-40° F to 122° F)**

HUMIDITY RANGE

15%-95% Non-condensing

WIRELESS

Optional LENS™ Wireless, proprietary mesh network

Frequency: ISM license-free band (2.4 GHz)

Max Peers: 25 devices per network group

Range: 100 m (300 ft) line of sight, face-to-face

Encryption: AES-128

Approvals: FCC Part 15, IC, CE/RED, others†

DISPLAY/READOUT

Backlit liquid crystal display (LCD)

POWER SOURCE/RUN TIME

Rechargeable lithium-ion battery pack with LEL

(12 hours typical @ 20 ºC) – without pump

Rechargeable extended-range lithium-ion battery pack with LEL

(23 hours typical @ 20 ºC) – without pump
(18 hours typical @ 20 ºC) – with pump

 Rechargeable lithium-ion battery pack with IR

(36 hours typical @ 20 ºC) – without pump

Rechargeable extended-range lithium-ion battery pack with IR

(72 hours typical @ 20 ºC) – without pump
(32 hours typical @ 20 ºC) – with pump

ALARMS

Four visual alarm LEDs (two red, two blue);

95 decibel (dB) audible alarm at a distance of 10 cm (3.94 in);

Vibration alarm

SUPPLIED WITH MONITOR

Calibration Cup (Ventis), Sample Tubing (Ventis with pump), Reference Guide

REFERENCE GUIDE LANGUAGE

English (1), French (2), Spanish (3), German (4), Italian (5), Dutch (6), Portuguese (7), Polish (A)

SENSORS

Combustible Gases/Methane – Catalytic Bead
O
2, CO, CO/H2 low, H2S, HCN, NH3, NO2, PH3, SO2– Electrochemical

CH4, CO2/LEL, CO2/CH4 – Infrared

MEASURING RANGES

Catalytic Bead

Combustible Gases: 0-100% LEL in 1% increments

Methane (CH4): 0-5% of vol. in 0.01% increments

Electrochemical

Ammonia (NH3): 0-500 ppm in 1 ppm increments

Carbon Monoxide (CO): 0-2,000 ppm in 1 ppm increments

Carbon Monoxide (CO/Hlow): 0-1,000 ppm in 1 ppm increments

Carbon Monoxide/Hydrogen Sulfide: CO: 0-1,500 ppm in 1 ppm increments

H2S: 0-500 ppm in 0.1 ppm increments

Hydrogen Sulfide (H2S): 0-500 ppm in 0.1 ppm increments

Hydrogen Cyanide: 0-30 ppm in 0.1 ppm increments

Nitrogen Dioxide (NO2): 0-150 ppm in 0.1 ppm increments

Oxygen (O2) (Standard/Long-Life): 0-30% of vol. in 0.1% increments

Phosphine (PH3): 0-10 ppm in 0.01 ppm increments

Sulfur Dioxide (SO2): 0-150 ppm in 0.1 ppm increments

Infrared

Methane (CH4):

0-5% vol in 0.01% increments

5-100% vol in 0.1% increments

Carbon Dioxide/Combustible:

CO2: 0-5% vol in 0.01% increments

LEL: 0-100% LEL in 1% increments

Carbon Dioxide/Methane:

CO2: 0-5% vol in 0.01% increments

CH4: 0-5% vol in 0.01% increments

CH4: 5-100% vol in 0.1% increments

Approvals & Certifications

UL:

Class I, Division 1, Groups A, B, C, and D, T4
Class II, Division 1, Groups E, F, and G, T4
Class I, Zone 0, AEx ia IIC, T4
Class I, Zone 1, AEx d ia II C, T4, with IR sensor

ATEX:

Equipment Group and Category II 1G, Ex ia IIC, Ga, T4
Equipment Group and Category II 2G, Ex d ia IIC, Gb, T4, with IR sensor

IECEx:

Class I, Zone 0, Ex ia IIC, Ga, T4
Class I, Zone 1, Ex d ia IIC, Gb, T4, with IR sensor

CSA:

Class I, Division 1, Groups A, B, C, and D, T4
Class I, Zone 1, Ex d ia IIC, T4
C22.2 No. 152 for % LEL reading only

MSHA:

30 CFR Part 22; Permissible for underground mines

PADEP:

Permissible for PA Bituminous underground mines

InMetro:

Ex ia IIC T4 Ga, -40 °C ≤ Ta ≤ 50 °C,
Ex d ia IIC T4 Gb with IR sensor,
-20 °C ≤ Ta ≤ 50 °C with IR sensor

ANZEx:

Ex ia I Ma / Ex ia IIC T4 Ga, -40 °C ≤ Ta ≤ +50 °C,
Ex d ia I Mb / Ex d ia IIC T4 Gb with IR sensor,
-20 °C ≤ Ta ≤ 50 °C with IR sensor

China Ex:

Ex ia IIC T4 Ga, -40 °C ≤ Ta ≤ 50 °C,
Ex d ia IIC T4 Gb with IR sensor,
-20 °C ≤ Ta ≤ 50 °C with IR sensor

* These specifications are based on performance averages and may vary by instrument.

** Operating temperatures above 50 °C (122 °F) may cause reduced instrument accuracy. Operating temperatures below -20 °C (-4 °F) may cause reduced instrument accuracy and affect display and alarm performance. See Product Manual for details.
